De Aire Variable Speed Air Compressor 15hp Industrial 15 Hp Rotary Screw Compressor

Name: De Aire Variable Speed Air Compressor 15hp Industrial 15 Hp Rotary Screw Compressor
Brand: Dehaha
Price: 1 USD

China De Aire Variable Speed Air Compressor 15hp Industrial 15 Hp Rotary Screw Compressor wholesale

Place of Origin : Jiangsu, China

Brand Name : Dehaha

Model Number : CPMZY15

Packaging Details : Plywood case

Supply Ability : 600 Set/Month

Price : Negotiate

Certification : CE/ISO9001

MOQ : 1set

Payment Terms : T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.

Delivery Time : 20 days

Product name : Screw Compressor

Type : Screw

Configuration : Stationary

Power Source : AC POWER

Lubrication Style : Lubricated

Mute : Yes

Air delivery : 37cfm 1.05 m3/min

Voltage : 380V/50Hz/3ph Optional

Dimension(L*W*H) : 1882*790*1731mm

Weight : 572kg

Working Pressure : 16bar

Warranty of core components : 1 Year

Cooling method : by air

Air outlet size : G3/4"

Noise : less than 65dB(A)

Invertor : Inovance

Control : PLC

OEM : Offered

Contact Now

15hp Variable Speed Industrial de aire Rotary Screw Air Compressor with dryer

Specification

Model	CPMZY15
Type	twin-screw air compressor
Dimensions	1882×790×1732mm
Installation method	Fixed installation without foundation
Rated displacement	1.51m3/min
Rated exhaust pressure	1.58Mpa
Exhaust oil content	≤0.003 ppm
Exhaust pressure dew point	2~10°C
Compression stages	Single-stage
Transfer method	belt
Compression oil consumption	8L
Cooling method	Air cooling
Cooling air volume	3500 m3/h
Ambient temperature	0 ~ 45°C
Noise	≤65 dB
Weight	560kg

Notes:1. A represents air-cooling type,W represents water-cooling type;
2. Working Environment temperature: -5ºC~45ºC;
3. Discharge temperature is less than ambient temperature +10ºC~15ºC;
4. Drive Mode: belt driven;
5. Startup Mode: direct start under 11kw, and above 11kw;
6. Work Power: 380V / 50HZ, 460V / 230V / 6KV and 10KV voltages can be made for customers;
7. F.A.D volume flow test is according to ASMC PTC9 or ISO1217 standard (GB/T3853)

Product Feature

1. Germany Rotorcomp Air end

German technology, high efficiency, good cutting effect.

2. IE3 High efficiency motor

IP54/P55 high protection level

3. Manuli Italy Super Pipe

Anti-aging, Long service life.

High Polymer Material, High Intensity.

4. German original Mann filter

Air Filter, Purified Air from Very Beginning.

Oil Filter, Clean Oil Circulation.

Oil Separator, Purify Compressed Air.

150% Filtration by Serial Filter Paper Design

5. Low noise

All door panels are equipped with fireproof and thick sound-proof sponge.

Use thicker steel plates to make the shock-absorbing chassis.

6. The cold dryer and precision filter are equipped with an automatic drain valve to avoid manual draining.

De Aire Variable Speed Air Compressor 15hp Industrial 15 Hp Rotary Screw Compressor

Project Case

Packing & Delivery

Company Profile

FAQ

Q1:Are you factory or trading company?
A1: We are factory.

Q2:Where is your factory located? How can I visit there?
A2: Our factory is located in Qidong City, Jiangsu Province, China. We can pick up you from Shanghai, it’s about 1 hour from Shanghai Pudong Airport to our factory. Warmly welcome to visit us!

Q3: Will you provide some spare parts of the machines?
A3: Yes, of course.

Q4: Warranty terms of your machine?
A4: Two years warranty for Air End, one year for spare part.

Q5: How long will you take to arrange production?
A5:380V 50HZ we can delivery the goods within 14 days. Other electricity or other color we will delivery within 22 days.

Q6:How does your factory do regarding quality control?
A6:Quality is everything. we always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO9001:2015 authentication and CE certificate.

Q7: Can you accept OEM orders?
A7: Yes, with professional design team, OEM orders are highly welcome.
