Integrated 15hp 11kW 4 In 1 Air Compressor For Laser Cutting Machine 350 Litre Air Tank

Name: Integrated 15hp 11kW 4 In 1 Air Compressor For Laser Cutting Machine 350 Litre Air Tank
Brand: Dehaha
Price: 1 USD

China Integrated 15hp 11kW 4 In 1 Air Compressor For Laser Cutting Machine 350 Litre Air Tank wholesale

Place of Origin : Jiangsu, China

Brand Name : Dehaha

Model Number : CPMZY15

Packaging Details : Plywood case

Supply Ability : 60 Set/Month

Price : Negotiate

Certification : CE/ISO9001

MOQ : 1set

Payment Terms : T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.

Delivery Time : 20 days

Type : Screw

Configuration : Stationary

Power Source : AC POWER

Lubrication Style : Lubricated

Mute : Yes

Voltage : 380V/50Hz/3ph Optional

Dimension(L*W*H) : 1882*790*1731mm

Weight : 572kg

Working Pressure : 16bar

Warranty of core components : 1 Year

Gas Type : Air

Air delivery : 37cfm 1.05 m3/min

Pressure : 16bar

Motor power : 15hp 11kW Permanent magnet variable

Cooling method : by air

Air outlet size : G3/4"

Noise : less than 65dB(A)

Invertor : Inovance

Control : PLC

OEM : Offered

Contact Now

4 in 1 Integrated Laser Cutter Screw Air Compressor Price with 350 Litre Air Tank

Model:CPMZY15A

Air delivery: 1.16m³/min

Working pressure: 16bar

Dimension:1900×700×1650mm

Compression oil amount:10L

Cooling air volume:350m3/h

Noise:≤65db

Speed:2930r/min

Air tank: 350L

Air dryer: 16bar/2.4m3/2-10℃

Filter: 16bar/2.8m3/4 pcs
Start mode: frequency conversion start

Laser cutting machine power: Below 6000W Filter fineness, use four stage filters, particle
content≤0.01μm oil content≤0.003PPM

Equipment configuration: screw air compressor, air tank, air dryer, four stage filters, auto drain valve, inverter.

Pressure differentiation of integrated screw air compressor

1. High pressure series

(1) The appearance is integrated, with air tank and air dryer

(2) The pressure range is 16bar (232psi) -30bar (435psi)

(3) Divided into fixed speed and permanent magnet frequency conversion series

2. Ordinary pressure series

(1) The appearance is integrated, with air tank and air dryer

(2) The pressure range is 7bar (101.5psi) -13bar (188.5psi)

(3) Divided into fixed speed and permanent magnet frequency conversion series

Technical Parameters

Model	Capacity (m3/min)	Pressure (Bar )	Power (kw)	Noise (DB)	Outlet diameter	Dimension(mm)	Weight (kg)	Air tank (L)	Exhaust oil content(ppm)
DBZY-10A	0.55	1.58	7.5	65	G3/4	14187001500	395	260	0.01
DBZY-15A	1.05	1.58	11	65	G3/4	18827901731	560	500	0.01
DBZY-20A	1.51	1.58	15	65	G3/4	18827901731	572	500	0.01
DMZY-15A	1.05	1.58	11	65	G3/4	18827901731	560	500	0.01
DMZY-20A	1.52	1.58	15	65	G3/4	18827901731	572	500	0.01
DMZY-30A	2.41	1.58	22	68	G3/4	188210811801	630	500	0.01
DCZY-30A	2.21	1.58	22	68	G3/4	188210811801	630	500	0.01
CPBZY15A	1.14	1.58	15	65	G3/4	19007001650	520	350	0.01
CPMZY15A	1.14	1.58	15	65	G3/4	19007001650	520	350	0.01
